FRP MEMBRANE HOUSINGS W80S1200
FRP MEMBRANE HOUSINGS W80S1200W80S1200 FRP MEMBRANE HOUSINGS

W80S1200 FRP MEMBRANE HOUSINGS

Winder frp membrane housing pressure vessels


Side Entry Design

Design/Operation Pressure: 1200Psi

Accommodates 1-8 standard Membrane Element

Element length: 40" x (1-8)

Applicable to: DOW, HYDRANAUTICS, OSMONICS, KOCH, TORAY, CSM, VONTRON,BDX, etc.

Standard: ASME, CE, ISO9001, ISO14001


W80S1200 (DN40 DN50 DN65 side entry).pdf

W80S1200 (DN80侧口).pdf



Inquire Now
Share:
Download
FRP MEMBRANE HOUSINGS W80S1200W80S1200 FRP MEMBRANE HOUSINGS

Winder frp membrane housing pressure vessels


Side Entry Design

Available in 300-2000 psi pressure rating

Accommodates 1-8 standard Membrane Element

Element length: 40" x (1-8)

Applicable to: DOW, HYDRANAUTICS, OSMONICS, KOCH, TORAY, CSM, VONTRON,BDX, etc.

Standard: ASME, CE, ISO9001, ISO14001


Key Features:

Operating Temp Range: -10°C ---66°C

Internal permeate port not to exceed 125PSI(0.88 MPa)

Operating pH Range: 3 – 11

Cleaning pH Range: 2 – 12 (less than 30 minutes)

Mirror inner wall and brightly surface.

Multi-ports option

White color is as standard. Customized colors are also available.


Quality Assurance

Hydro-static Leakage Test Pressure:

Standard:

100% test, not sampling

— 100,000 times cyclic fatigue test

— Burst test with 6 times of its operating pressure

— 100% QA test with 1.1x design hydraulic pressure.

ASME: 1.1x Design Pressure

— 100% QA inspection and cleaning before final

packaging and delivery to customers.

— Submitted for NSF standard 61


Applications:

Winder FRP membrane housing pressure vessels are widely used for industrial waste water treatment, seawater desalination, brackish water desalination, RO system for electronics, electric power, food & beverage, metallurgy, chemical, pharmaceutical and other fields.


Notice:

Please operate in accordance with User Guide!

All information is subject to change without prior notice. Please contact us for the latest product information and specifications.
